P.P Pleated Cartridge

Polypropylene filter cartridges are precisely manufactured for use in critical filtration applications within food, pharmaceuticals, biotech, dairy, beverages, brewing, semiconductor, water treatment & other demanding process industries.

Polypropylene pleated cartridges use the very latest gradient density micro fiber media technology to provide a combination of excellent micron ratings, high flow rates and high contaminant holding capacities. A special combination of polypropylene media with variation in the fiber diameter creates a gradient density matrix, ranging from open on the outside to finer on the inside, thereby providing a filter with in filter, which considerably increases contamination holding capacity & throughputs.

All components used in the manufacturing process are biologically safe, chemically inert and meet FDA and other international quality requirements. Polypropylene offers an extremely broad chemical compatibility making it suitable for many applications.


Enquiry Call Now


Features & Benefits

  • All polypropylene construction
  • Absolute & nominal efficiency
  • 0.1 to 40 Micron ratings
  • Gradient density micron fiber media
  • High surface area more than 0.5 m2
  • Robust outer cage
  • Biologically safe
  • Wide chemical compatibility
  • No fiber migration
  • Thermally welded construction
  • FDA approved filters per 10"filter
  • End connections to fit all standard housings

Technical Specifications

Sizes 10”, 20”, 30”, 40” Long
Micron Rating 0.1, 0.2, 0.45, 1, 5, 10, 20 Micron
Outer Diameter 69 mm
Inner Diameter 28 mm

Applications

Fine Chemicals and Pharmaceuticals

  • D.I. Water
  • R.O.Pre filtration
  • Biological Fluids
  • Oral Drugs

Ophthalmic Liquids

  • Anti-Halation Coatings
  • Developer Chemicals
  • Emulsions
  • Gelatins

Beverages

  • Wine
  • Alcohols
  • Fruit Juice
  • Beer

Electronic and Semi-Conductor

  • De-ionized Water Prefiltation
  • Magnetic tapes
  • Premix Resins
  • Tape Coatings
  • Photoresists
  • Metal Oxide Dispersions
  • Solvents

Configuration

  • Double Open Type (DOE Type)
  • Code 7S (226 'O' Ring Design / Bayonet)
  • Code 7F (226 'O' Ring Design / Flat)
  • Code 3S (222 'O' Ring Design / Bayonet)
  • Code 3F (222 'O' Ring Design / Flat)

Construction

Filter Media 100 % Melt blown micro denier polypropylene fiber
Support Media Polypropylene fiber
Inner Core High strength polypropylene
Outer Core High strength polypropylene
End Caps High strength polypropylene
O Ring / Gaskets EPDM / Buna N / Silicone / Viton
